EYCY 0,6/1kV - PVC Insulated Heavy Current Cable with Concentric Conductor
Description
Application:
In dry, humid and wet locations, cable ducts, outdoors, underground and in water.
Construction:
Conductor - Copper : solid (RE)
Insulation - Polyvinylchloride (PVC)
Filling - core covering or taping
Screening - concentric conductor of copper wires and copper tape
Outher sheath - Polyvinylchloride (PVC)
Standards:
OVE / ONORM E 8200-603
HD 603 S1
IEC 60228
License:
This cable is VDE certified
Core Identification:
JZ: One core green/yellow, other cores are black with figures
OZ: every core is black with figures
Specifications
Electrical Performance:
Nominal Voltage: 600/1000 Volt
Test Voltage: [V]AC 4000
Short circuit time max. [sec] 5
Bending radius: Single core x diameter 12
Multicore x diameter 15
Temperature range:
In motion °C -5°C till +70°C
Fixed °C -30°C till +70°C
Max. temp. short circuit °C 160°C
Fire classification CPR class:
EN 50575 - Eca
