Safety cables are used in all locations where a high degree of protection against fireand fire-damage has to be provided for human life and equipment and are, therefore, subject to high security requirements. These cables may be used indoors and outdoors. They may not be installed directly into the ground and into the water. This cable conforms to Safety Class II standards.
Conductor - Copper : solid (RE) / Stranded (RM/SM)
Insulation - Halogen-Free, Cross linked Polyethylene
Filling - Core covering of a halogen-free compound
Outher sheath - Halogen Free Flame Retardant (HFFR)
HD 604 S1; IEC 60228
This cable is OICPE certified
Nominal Voltage: 600/1000 Volt
Short circuit time max. [sec] 5
In motion °C -35°C till +90°C
Max. short-circuit temp. short circuit: 250°C
1 core: B2 ca-s1a,d2,a1;
Multicore: Cca-s1a,d2,a1
