NYBY 0,6/1kV - PVC Insulated and sheated power cable, steel tape armored
Description
Application:
In fixed installations, in dry, wet places, outdoors or in the ground. Its construction allows use in places where there are risks of mechanical damage.
Construction:
Conductor - Copper Solid (RE) / Stranded (RM/SM)
Insulation - Polyvinylchloride (PVC)
Filling - PVC or plastic strips
Armor - Cold rolled steel strip
Outer sheath - Polyvinylchloride (PVC) Black, UV - resistant
Standards:
IEC 60228
HD 603 S1
Core identification:
According to SR HD 308 S2
Specifications
Electrical Performance:
Nominal Voltage: 600/1000 Volt
Test Voltage: [V]AC 4000
Short circuit time max. [sec] 5
Minimum radius of curvature Min 12 x cable diameter
Temperature range:
-30°C till +70°C
Max. short circuit temp. °C 160°C
Fire classification CPR class:
EN 50575 - Eca
